- The most compact tractor model available for sale in Sierra Leone.
- The engine is smaller in size i.e. 2.5D.
- It comprises 50hp of horsepower.
- It is pocket-friendly and its spare parts are easily available across the African market.
- Manual transmission is the mode of transmission in this model.
- It exists in the 2WD option.
- It consists of durable spring suspension as well as a deluxe seat.
Max. Engine Power at 2,250 rpm | 50 (B.S) hp |
Maximum Torque at 1,400 rpm | 172Nm |
Maximum PTO Power at Rated | 44hp |
Engine Speed | |
*Certified at BS AU 141a 1971 | **Manufacturer’s Estimate |
Voltage | 12V, Negative Earth |
Battery | 110 Ah |
Starter | 2.2 kW |
Alternator | 32 Amp |
Type | Sliding Spur |
Number of Gears | 8 Forward, 2 Reverse |
Road Speed at 2,250 | Engine RPM with 12.4/11-28 Tyres |
Gear | Speed (km/hr) |
Forward 1 (First Low) | 2.7 |
Forward 2 | 3.9 |
Forward 3 | 5.3 |
Forward 4 | 7.2 |
Forward 5 (First High) | 10.6 |
Forward 6 | 15.4 |
Forward 7 | 21.3 |
Forward 8 | 28.6 |
Reverse 1 (Low) | 3.6 |
Reverse 2 (High) | 14.5 |
Functions | Draft Control, Position Control |
Pump Type | Response Control, Constant Pumping |
Maximum Oil Flow | Reciprocating Ferguson Pump |
Maximum Pressure | 16L / mix |
Max. Lift Capacity with Lower | 19.2 Mpa |
Links Horizontal | Max. Lift Capacity with Lower 1,415 kg |
Lower Links | With Cat, I & II Interchangeable Balls |
Brake Type | Out Board Drum Brakes |
Actuation | Mechanical, Independant or Locked Together, Hand Lever Operated |
Parking Brake | Mechanical |
Different Lock | " |
Front | 6.00 - 16 (6PR) |
Rear | 12.4 / 11 - 26 (6PR) |
Type | Dual Clutch |
Diameter | 305 x 254 mm |
Type | Box Section, Adjustable |
Diameter | 305 x 254 mm |
Steering | Manual |
Front Axle | 1,245 - 1,854 mm |
Rear Axle | 1,321 - 1,930 mm |
Type | Diesel AD 3.1524 |
No. of Cylinders | 3 |
Injection | Direct |
Bore | 91.4mm |
Stroke | 127.0mm |
Capacity (litres) | 2.5 L |
Compression Ratio | 16.5:1 |
Aspiratio | Natural |
Starting Aid | Thermostart |
Throttle Control | Hand and Feet |
Cooling | Water |
Air Cleaner Type | Oil Bath |
Air Pre-Cleaner | Over Bonnet, Air Swirl |
Fuel Filter | Dual, High Capacity |
Exhaust | 5Vertical |
Type | Live |
Engine Speed at 540 pto rpm | 1,789 rpm |
Shaft Diameter | 35mm |
No. of Splines | 6 |
Guages | echnometer, Hourmeter, Fuel Level, Battery Condition & Water Temperature |
Warning Lights | Direction Indicators, Battery Charge, Headlight Main Beam, Low Engine Oil, Pressure & Brake Lights |
Functions | Draft Control, Position Control |
Pump Type | Response Control, Constant Pumping |
Maximum Oil Flow | Reciprocating Ferguson Pump |
Maximum Pressure | 16L / mix |
Max. Lift Capacity with Lower | 19.2 Mpa |
Links Horizontal | Max. Lift Capacity with Lower 1,415 kg |
Lower Links | With Cat, I & II Interchangeable Balls |
Gross Weight | 1,650 kg |
Wheel Base | 1,892 mm |
Overall Length | 3,260 mm |
Overall Width (Min) | 1,651 mm |
Over Exhaust | 2,145 mm |
Over Steering Wheel | 1,410 mm |
With Brakes | 5,560 mm |
Without Brakes | 6,200 mm |
Fuel Tank | 47.5L |
Engine Pump | 6.8L |
Cooling System | 10.2L |
Hydraulic System | 36.0L |
Steering Box | 0.9L |
Oil Bath Air-Cleaner | 0.5L |
